How to master the method of led installation

2020-02-10

  In order to master the installation method of LED, there are some skills, Master Chen, who has worked for many years, introduced me, how he mastered the installation method of led, because in many occasions, it is necessary to apply to LED. For example: solar LED lights, LED street lights, and LED display. Each installation method is different! So it is worth everyone to learn, so the theme shared by Xiaobian today is: how to master the method of led installation?

1, LED street light hanging type


1) This installation method is mainly used for indoor and semi-outdoor


2) Usually used for passageways, corridor entrances, but also stations, train stations, subway entrances, etc.


3) For highways, railways, and traffic induction on highways


4) Screen design generally adopts a one-piece cabinet design or lifting structure design.


2, LED display Mosaic installation


1) The entire LED display body is embedded in the wall, and the display plane is at the same level as the wall surface.


2) Generally adopt a simple box design


3) Routine pre-maintenance (pre-maintenance design)


4) This installation method is used outdoors and indoors, but it is usually suitable for screens with small spacing and small display area.


5) Usually used for building entrances, building halls, etc.


3, high-power LED street lamp column type (single and double column)


There are a variety of column installation methods, commonly used for outdoor billboards:


1) Single column installation: suitable for small screen applications


2) Double column mounting: suitable for large screen applications


3) Closed maintenance channel: suitable for simple cabinets


4) Open maintenance channel: applicable to standard cabinets


4, wall hanging installation method


1) This installation method is usually used indoors or semi-outdoors


2) The display area of the screen is small, usually no maintenance access space is left, the entire screen is taken down for maintenance, or it is made into a folded integrated frame.


3) The screen area is slightly larger, and the pre-maintenance design is generally adopted (that is, the pre-maintenance design is usually assembled by the column).


5. Installed LED street lights on the roof

1) This installation method shows that the steel frame structure can resist wind power is key


2) Usually installed at a tilt Angle, or the module is designed to tilt 8°


3) Mainly used for outdoor advertising display


6, rental lifting method


LED installation precautions:


Do not make the lifting screen larger. Generally, it is required to be less than 6M x 10M. Special cabinet materials and curtains are excluded. The top is equipped with a lifting beam and the bottom is equipped with a bottom beam. The lifting beam is used to lift the screen.


Between the row and the row box, the lifting mechanism is connected, and the horizontal box is fixed with a lock.


Lifting mechanism: gear type, taper type, bolt type.


It has the following different characteristics:


1. Gear type is more expensive and more beautiful.


2. Conical price moderate and reliable.


3. Bolt type is cheap, reliable, troublesome to assemble, suitable for the situation of not repeated disassembly.


In actual engineering installation, there are other installation methods, which are not described here. These six types are relatively common installation methods and relatively easy to install. The main requirement is that the installer requires the installation process to be strictly executed and to ensure that the screen body is installed and qualified. Only in this way can we truly achieve the communication effect of the LED display and meet the requirements of advertisers. How to master the method of led installation? Small series for you to share here, need products can look at the product center of this website.
